Plugs TP 1 5x25 100 enkelte plugs
| Varenr: | 1001025 |
| El nr: | 9139129086 |
| EAN13 nr: | 7315880100003 |
| Pakning: | 100stk |
 |
| Ambient air temperature for operation | -50...80 °C |
| Colour tint | Gul |
| Device application | Lightweight installation |
| Diameter | 5.5 mm |
| Drilling depth | >= 25 mm |
| Drilling diameter | 5 mm ALC concrete 5.5 mm brick 5.5 mm concrete |
| EAN-Code | 7315880100003 |
| Enhedens korte navn | TP |
| Forudsat udstyr | Without screw |
| Local distributor code | 9139129086 |
| Længde | 22 mm |
| Material | PEHD (polyethylene high density) |
| Pratical load capacity | Pull-out load: 0.04 kN til low density concrete 500 and expanded clay (sikkerhedsfaktor:6) Shear: 0.1 kN til low density concrete 500 and expanded clay (sikkerhedsfaktor:4.5) Pull-out load: 0.2 kN til solid brick (sikkerhedsfaktor:6) Shear: 0.4 kN til sol |
| Pratical load capacity | Pull-out load: 4 kg til low density concrete 500 and expanded clay (sikkerhedsfaktor:6) Shear: 10 kg til low density concrete 500 and expanded clay (sikkerhedsfaktor:4.5) Pull-out load: 20 kg til solid brick (sikkerhedsfaktor:6) Shear: 40 kg til solid bri |
| Produkttype | Wall plug |
| Quantity per set | Sæt af 100 |
| Range of product | Thorsman |
| Salg pr udelelig antal | 1 |
| Skruediameter | 3.5...5 mm |
| Stock Code | On stock |
| Vægt | 0.00035 kg |
