Trykkontakt iPB 20 A 1NL rød LED 250 V AC 0,3W B:18 mm
| Varenr: | A9E18037 |
| El nr: | 3317000392 |
| EAN13 nr: | 3606480088292 |
| Pakning: | 1stk |
 |
| [Ie] rated operational current | 20 A |
| [Ue] rated operational voltage | 250 V AC |
| 9 mm pitches | 2 |
| Ambient air temperature for operation | -20...50 °C |
| Ambient air temperature for storage | -40...80 °C |
| Bulb lifespan | 100000 H |
| Cap/operator or lens colour | Red |
| Colour | White |
| Comb busbar distribution block compatibility | Upside: ProDis Upside: Librio Upside: Clario |
| Contacts type and composition | 1 NC |
| Connections - terminals | Staggered tunnel terminal 2 cable(s) 2.5 mm² rigid without Staggered tunnel terminal 2 cable(s) 2.5 mm² rigid with Staggered tunnel terminal 2 cable(s) 2.5 mm² flexible without Staggered tunnel terminal 2 cable(s) 2.5 mm² flexible with |
| Control type | 1 pushbutton grey |
| Depth | 71.5 mm |
| Device short name | IPB |
| Electrical durability | AC-22: 30000 cycles AC 50/60 Hz |
| Height | 82 mm |
| Light source | LED |
| Mounting mode | Fixed |
| Mounting support | 35 mm symmetrical DIN rail |
| Period | 18 months |
| Power consumption | 0.3 W |
| Product or component type | Pushbutton |
| Range of product | IPB |
| Relative humidity | 95 % ( 55 °C ) |
| RoHS EUR conformity date(YYWW) | 1001 |
| RoHS EUR status | Compliant |
| Signalling circuit voltage | AC: 110...230 V 50/60 Hz |
| Standards | IEC 60669-1 IEC 60947-5-1 |
| Tropicalisation | 2 |
| Width | 18 mm |
