Betonanker M8x95 el-galvaniseret
| Varenr: | IMT38008 |
| El nr: | 9139133522 |
| EAN13 nr: | 3606480214691 |
| Pakning: | 100stk |
 |
| Accidental action | Pull-out load: 1170 kg til concrete C20/C25 |
| Ambient air temperature for operation | -20...60 °C |
| Atmospheric-corrosivity category | C2 |
| Borediameter | 8 mm |
| Drilling depth | 93 mm |
| EAN-Code | 3606480214691 |
| Enhedens korte navn | TEX |
| Forudsat udstyr | Nut Washer |
| Indbygningsdybde | 55 mm |
| Installationstype | Indoor |
| Local distributor code | 9139133522 |
| Material | Stål electro-zinc |
| Montagevejledning | Concrete Natural rock |
| Pratical load capacity | Pull-out load: 4.4 kN til concrete C20/C25 |
| Product end of life instructions | Need no specific recycling operations |
| Productcertificeringer | SITAC No. SC0268-10 |
| Produkttype | Through bolt |
| Quantity per set | Sæt af 50 |
| Range of product | Thorsman |
| RoHS | Compliant - siden 0852 - Schneider Electric declaration of conformity |
| Screw length | 95 mm |
| Serviceability limit state | Pull-out load: 900 kg til concrete C20/C25 |
| Stock Code | On stock |
| Sustainable offer status | Not Green Premium product |
| Tilspændingsmoment | 23 N.m |
| Tråd type | M8 |
| Tykkelse | 0...30 mm:[sapce]fixture |
| Ultimate limit state | Pull-out load: (sikkerhed cl 2)530 kg til concrete C20/C25 Pull-out load: (sikkerhed cl 1)590 kg til concrete C20/C25 |
Yderliger oplysninger:
Se venligst SE katalog©Schneider Electric A/S 2025
