Fast tidsforsinkelse til MN - 48 V AC - bruges sammen med refnr. LV429412
| Varenr: | LV429426 |
| El nr: | 3322702070 |
| EAN13 nr: | 3606480019180 |
| Pakning: | 1stk |
 |
| Control circuit voltage | 48 V AC 50/60 Hz |
| Device short name | MN delay unit |
| Enhedens korte navn | MN tidsforsinket enhed |
| Forsyningens holdeeffekt | 4.5 VA |
| Forsyningens indkoblingseffekt | 200 VA |
| Grænse for udløsespænding | 0.85 x Un closing 0.35...0.7 x Un åben |
| Impulse duration | 200 ms |
| Impulsvarighed | 200 ms |
| Montage | Fixed |
| Mounting mode | Fixed |
| Product end of life instructions | Need no specific recycling operations |
| Product environmental profile | Available Download Product environmental |
| Product or component type | Time delay auxiliary |
| Produkttype | Time delay auxiliary |
| Range of product | NSX100...250 NSX400...630 Easypact CVS100...250 Easypact CVS400...630 NSX100...250 DC NSX400...630 DC |
| Range of product | NSX100...250 NSX400...630 Easypact CVS100...250 Easypact CVS400...630 NSX100...250 DC NSX400...630 DC PowerPact multistandard |
| REACh | Reference not containing SVHC above the threshold |
| RoHS (date code: YYWW) | Compliant - since 0909 - Schneider Electric declaration of conformity |
| RoHS EUR conformity date(YYWW) | 0909 |
| RoHS EUR status | Compliant |
| Spændingsudløsertype | Underspænding udløser |
| Styrespænding | 48 V AC 50/60 Hz |
| Supply holding power | 4.5 VA |
| Supply inrush power | 200 VA |
| Sustainable offer status | Green Premium product |
| Threshold tripping voltage | 0.85 x Un - during closing time 0.35...0.7 x Un - during opening time |
| Time delay range | 0.25 s |
| Voltage release type | Undervoltage release |
Yderliger oplysninger:
Se venligst SE katalog©Schneider Electric A/S 2025
