| [Ie] rated operational current | 10 A UL 16 A conforming to EN/IEC 60947-7-1 |
| [Ue] rated operational voltage | 300 V UL 400 V conforming to EN/IEC 60947-7-1 |
| Ambient air temperature for operation | -40...130 °C conforming to VDE 0304-T21 -40...130 °C conforming to IEC 60216-1 |
| Antal klemmer | 2 |
| Antal måleindgange | 0 |
| Associated connection component | Diode Blade Cylindrical fuse |
| Bredde | 5.2 mm |
| Creep resistance | 500 CTI (> 400 kB) conforming to VDE 0303-T30 500 CTI (> 400 kB) conforming to IEC 60093 |
| Dielectric constant | 3,7 at 1 MHz |
| Dielektrisk gennemslagsholdbarhed | 1000 V conforming to IEC 60243-1 |
| Dielektrisk tab | 0,01 at 1 MHz conforming to VDE 0303-T4 0,01 at 1 MHz conforming to IEC 60250 |
| EAN-Code | 3606480532948 |
| Enhedens korte navn | TRR |
| Farve | Harmaa |
| Fastbindingslængde for ledning | 10 mm |
| Flammemodstand | V0, thickness0.8 mm conforming to UL 94 |
| Højde | 55 mm |
| Klemrækketype | Removable carrier disconnect |
| Kompatibilitet | Spacial enclosures |
| Ledertværsnit | 0.8...4 mm², solid 0.08...2.5 mm², fleksibel uden |
| Local distributor code | 1512721339 |
| Længde | 107 mm |
| Material | Polyamide 6/6 (insulating case) |
| Montage | Clip-on |
| Nominal cross section | 2.5 mm² |
| Overflademodstand | 1000 G? conforming to VDE 0303-T30 1000 G? conforming to IEC 60093 |
| Product name | TR |
| Productcertificeringer | CSA GOST UL |
| Produkttype | Terminal blok |
| Quantity per set | Sæt af 50 |
| Range | Linergy |
| Reguleringskompatibilitet | TeSys Pragma Kaedra Spacial Prisma - Pack Prisma - PH Prisma - P Prisma - G |
| Resistivitet | 10000 M?.m conforming to VDE 0303-T30 10000 M?.m conforming to IEC 60093 |
| Sikringsstørrelse | 5 x 20 mm 6 x 32 mm |
| Stock Code | On stock |
| Terminal block level | 2 |
| Tilslutningsklemmer | 1 x fjeder terminal: beskyttelse nedad 1 x fjeder terminal: mod strømmen |
| Tilslutningsposition | Top |
| Tool type | Disconnection: flat screwdriver Connection: flat screwdriver |
| Vægt | 26 g |
