Hukommelseskort til LMC078 motion controller
Varenr: TMASD2
Produktet findes ikke i SAP!
 |
| Accessory / separate part category | Separate parts |
| Accessory / separate part type | SD card |
| Ambient air temperature for operation | -10...70 °C |
| Ambient air temperature for storage | -25...85 °C |
| Data retention time | 10 yr at 25 °C |
| Depth | 2.1 mm |
| Height | 32 mm |
| Memory capacity | 1 GB |
| Memory type | Flash |
| MTBF reliability | 3000000 H |
| Number of read/write cycles | 3000000 |
| Product compatibility | LMC... |
| Product specific application | Application backup Program transfer Update the internal software File storage |
| Product weight | 0.004 kg |
| Range compatibility | Modicon LMC078 |
| Range of product | Modicon LMC078 |
| Relative humidity | <= 95 % (without condensation) |
| Resistance to electrostatic discharge | 15 kV in air conforming to EN/IEC 61000-6-2 4 kV on contact conforming to EN/IEC 61000-4-2 |
| Shock resistance | 15 gn conforming to EN/IEC 61131-2 2007 |
| Vibration resistance | 1 gn conforming to EN/IEC 61131-2 2007 |
| Width | 24 mm |
Yderliger oplysninger:
Se venligst SE katalog©Schneider Electric A/S 2025
