| Ambient air temperature for storage | -25...70 °C |
| Analogue I/O processor capacity | 24 I/O |
| Anbefalede temperatur ved betjening | 0...60 °C |
| Antal digitale I/O pr. CPU | 512 I/O |
| Antal modulpladser | <= 32 |
| Antal racks | 4 4/6/8 slots 2 12 slots |
| Antal specifikke kanaler | <= 8 |
| Applikationsstruktur | 1 fast task 1 master task 32 event tasks |
| Beskyttelsesbehandling | TC |
| Communication module processor | 2 1 |
| Driftshøjde | 0...2000 m |
| EAN-nummer | 3595863812558 |
| Ethernetport | 10BASE-T/100BASE-TX |
| Forureningsgrad | 2 |
| Integreret forbindelse | Non isolated serial link 2 female mini DIN RS485 19.2 kbit/s Ethernet TCP/IP RJ45 |
| IP kapslingsklasse | 18-22 |
| Kommerciel status | Commercialised |
| Lagerkode | Ikke på lager |
| Modulformat | Dobbel |
| Mærkning | CE |
| Overhead | 1 ms master task 0.3 ms fast task |
| Product end of life instructions | Need no specific recycling operations |
| Gennemføringstid pr. instruktion | 1.75...2.6 µs florerende punkt without PCMCIA card 1.75...2.6 µs florerende punkt with PCMCIA card 0.5 µs ord eller fastpunkt aritmetik with PCMCIA card 0.25 µs ord eller fastpunkt aritmetik without PCMCIA card 0.25 µs Boolean with PCMCIA card 0.19 µs Boo |
| Hukommelsesbeskrivelse | PCMCIA card 256 kB additional data storage Internal RAM (without PCMCIA card) 96 kB program and data Internal RAM (with PCMCIA card) 96 kB data Internal RAM (with PCMCIA card) 224 kB program |
| Lokal indikering | 1 LED gul transmission activity (TX) 1 LED gul reception activity (RX) 1 LED gul Ethernet link diagnostics (STS) 1 LED gul activity on TER or AUX terminal port (TER) 1 LED rød processor or system fault (ERR) 1 LED rød I/O module or configuration fault (I/ |
| Maximum size of object areas | 64 kB (DFB and EFB function blocks) unlocated internal data 64 %MWi internal words located internal data 64 %KWi constant words located internal data 4096 %Mi located internal bits 32 kB (elementary and derived data) unlocated internal data |
| Number of instructions per ms | 4.76 Kinst/ms 100 % Boolean without PCMCIA card 3.71 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card 3.1 Kinst/ms 100 % Boolean with PCMCIA card 2.1 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card |
| Productcertificeringer | ABS BV DNV GL LR RINA RMRS |
| Produktsortiment | Modicon Premium Automation platform |
| Produkttype | Unity processor |
| REACh | Reference not containing SVHC above the threshold |
| Relativ fugtighed | 5...95 % without condensation for storage 10...95 % without condensation for operation |
| RoHS (date code: YYWW) | Compliant - since 0933 - Schneider Electric declaration of conformity |
| Software udpegning | Unity Pro |
| Standarder | 73/23/EEC 89/336/EEC 92/31/EEC 93/68/EEC CSA C22.2 No 142 IEC 61131-2 UL 508 CSA C22.2 No 213 Class I Division 2 Group A CSA C22.2 No 213 Class I Division 2 Group B CSA C22.2 No 213 Class I Division 2 Group C CSA C22.2 No 213 Class I Division 2 Group D |
| Strømforbrug | 1650 mA 5 V DC |
| Sustainable offer status | Ikke Green Premium produkt |
| Vægt | 0.74 kg |
